Boost your productivity
while being environmentally friendly with the 17” NEC MultiSync® E172M, an eco-conscious LED backlit LCD desktop monitor that enhances your computing experience. The LED backlighting allows for lighter weight and increased power savings compared to previous generation models, a carbon footprint meter for tracking the conservation of green gas emissions and Intelligent Power Manager (IPM) system.
These advantages, combined with an ergonomic design make this model ideal for corporate environments.
Benefits
- Input – Display can be used with one digital (DVI-D) and one analogue input.
- Affordable Green – low power consumption with latest W-LED backlight technology, EcoMode function and Carbon Footprint Meter / Carbon Savings Meter.
- Ergonomic Office – full height adjustability (50 mm), swivel, tilt and pivot functionality ensures perfect individual workspace set-up.
- Vesa Mount (100 mm) – allows to install the monitor via various mounting solutions.
- NaViSet Compatible – for comprehensive network-wide asset management and easier remote support.
Specifications
Product Information
Product Name
NEC MultiSync® E172M
Product Group
LCD 17" Enterprise Display
Order Code
60005020
Display
Panel Technology
TN with W-LED backlight
Screen Size [inch/cm]
17 / 43
Pixel Pitch [mm]
0.264
Brightness (typ.) [cd/m²]
250
Contrast Ratio (typ.)
1000:1
Viewing Angle [°]
170 horizontal / 160 vertical (typ. at contrast ratio 10:1); 170 horizontal / 170 vertical (typ. at contrast ratio 5:1)
Response Time (typ.) [ms]
5
Colours [Mio.]
16.7
Synchronisation Rate
Horizontal Frequency [kHz]
31.5 - 81.1
Vertical Frequency [Hz]
56 - 76
Resolution
Optimum Resolution
1280 x 1024 at 60 Hz
Supported
1024 x 768; 1152 x 864; 1152 x 870; 1280 x 960; 640 x 480; 720 x 400; 800 x 600; 832 x 624
Connectivity
Digital
1 x DisplayPort; 1 x HDMI
Analog
1 x VGA
Electrical
Power Consumption on Mode [W]
14 (typ.); 19 (max.); 9 (Eco Mode)
Power Savings Mode [W]
< 0.4
Power Supply
0.4 A/0.2 A; 100-120 V/220-240 V; internal power supply
Environmental Conditions
Operating Temperature [°C]
+5 to +35
Operating Humidity [%]
20 to 80
Ergonomics
Height adjustable Stand [mm]
50
Screen Tilt [°]
-5 to +20
Mechanical
Bezel Width [mm]
14.2 (left and right); 17.5 (top and bottom)
Dimensions (W x H x D) [mm]
368 x 358.5 - 408.5 x 230 (Landscape mode)
Weight [kg]
With stand: 4; Without stand: 2.8
VESA Mounting [mm]
100 x 100
Additional Features
Special Characteristics
17" (5:4) Highly efficient panel with white LED backlight saves more than 30 % energy; Carbon Savings Meter; NaViSet Administrator 2; Rapid Response Technology; Versatile installation (VESA standard), with integrated speakers (1+1 W); Windows 8 compatible
Colour Versions
Black Front Bezel, Black Back Cabinet
Cable Management
yes
Kensington security slot
yes
Plug and Play
DDC2B/2Bi; EDID Standard; VESA DDC/CI
Audio
Headphone Jack; Integrated Speakers (1 W + 1 W)
Adjust Functions
Auto Adjust; Brightness; Colour Temperature Control; Contrast; Fine Adjust (analog); Language Select; Monitor Information; NTAA (Non-Touch-Auto-Adjustment); On-Screen-Display (OSD) lock-out; Volume
Shipping Content
DisplayPort Cable; Monitor; Power Cable; Setup Guide
Safety and Ergonomics
CE; EAC; EnergyStar 8.0; FCC Class B; ISO 9241-307 (pixel failure class I); MPR II/ MPR III; RoHS; TCO 8.0; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA
Warranty
3 years warranty incl. backlight
Green Features
Energy Efficiency
Energy consumption: 9 kWh/1000 h; Energy efficiency class: C; LED backlight technology
Ecological Standards
Energy Star 8.0; ErP compliant; RoHS compliant; TCO 8.0
* EnergyStar 8.0
* TCO 8.0
