NEC MultiSync® EA241WU Ultra-Narrow Bezel – best productivity with tailored ergonomics plus style and performance to complement the modern office
With full height adjustability from 0 to 150 mm and 170° swivel functionality, this 24” display enables the user to create an individually tailored workspace. Furthermore, built-in Low Blue Light technology filters out hazardous blue light emissions whilst Flicker-Free technology eliminates the effect of flickering thus ensuring the well-being of the user. Fulfilling the demand for future-ready performance and delivering all the quality and reliability commensurate with the NEC brand, the EA241WU is well positioned to maximise office productivity.
Performance AH-IPS screen technology with LED backlit panel delivers 300 cd/m² of brightness whilst keeping power consumption to a minimum.
Benefits
- Ergonomic Office – full height adjustability (150 mm), swivel, tilt and pivot functionality ensures perfect individual workspace set-up.
- Auto-Adjust Power Consumption – to minimize unnecessary power usage, the Human and Ambient Light Sensors adjust the display brightness according to user presence and room lighting conditions.
- Protecting your eyes from strain and damage – Built-in Low Blue Light technology filters out hazardous blue light emissions whilst Flicker-Free technology eliminates any backlight flickering, thus protecting your eyes against cataracts and macular degeneration without compromise to true-to-life display colour performance.
- Best in form and function – future-ready design with 3-sided ultra-narrow bezel, available in black or white, complementing a fresh professional office interior.
- Business Class Image Quality – Advanced High-Performance IPS (AH-IPS) panel provides the very best viewing angles as well as noticeably better colour reproduction.
Specifications
Product Information
Product Name
NEC MultiSync® EA241WU
Product Group
LCD 24" Enterprise Display
Order Code
60004676 (BK),
60004677 (WH)
Display
Panel Technology
IPS TFT with W-LED backlight
Screen Size [inch/cm]
24 / 61
Screen Aspect Ratio
16:10
Pixel Pitch [mm]
0.270
Brightness (typ.) [cd/m²]
300
Contrast Ratio (typ.)
1000:1 (5000:1 dynamic contrast ratio)
Viewing Angle [°]
178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms]
5
Colours [Mio.]
16.77
Synchronisation Rate
Horizontal Frequency [kHz]
31.5 - 95
Vertical Frequency [Hz]
56 - 75
Resolution
Optimum Resolution
1920 x 1200 at 60 Hz
Supported
1024 x 768; 1280 x 1024; 1280 x 960; 1366 x 768; 1400 x 1050; 1440 x 900; 1600 x 1200; 1680 x 1050; 1920 x 1200; 640 x 480; 800 x 600
Connectivity
Digital
1 x DisplayPort; 1 x DVI-D; 1 x HDMI; USB ver. 3.0 (3 down / 1 up)
Analog
1 x D-sub 15 pin
Electrical
Power Consumption on Mode [W]
15 (Eco Mode 2); 20 (typ.); 47 (max.)
Power Savings Mode [W]
0.3
Power Supply
internal power supply
Environmental Conditions
Operating Temperature [°C]
+5 to +35
Operating Humidity [%]
20 to 80
Ergonomics
Height adjustable stand [mm]
150
Screen Tilt / Swivel [°]
-5 to +35; -170 to +170
Screen Rotate [°]
-90 to 90 (landscape to portrait mode)
Mechanical
Bezel Width [mm]
0.8 (left/right/top)
Dimensions (W x H x D) [mm]
With stand: 531.5 x 515.4 x 250
Weight [kg]
6.7
VESA Mounting [mm]
100 x 100
Additional Features
Special Characteristics
Ambient light sensor for optimized brightness levels; Carbon Footprint Meter; Carbon Savings Meter; ControlSync®; Customize Setting; DICOM preset; EcoModes; Human Sensor; LED Backlight Technology; NaViSet Administrator 2; Quick release Stand and Handle; sRGB Support; Touch Sensor Keys; USB ver. 3.0 (3 down / 1 up)
Colour Versions
Black Front Bezel, Black Back Cabinet; White Front Bezel, White Back Cabinet
Cable Management
yes
Kensington security slot
yes
Plug and Play
VESA DDC2B; VESA DDCi
Audio
Headphone Jack; Integrated Speakers (1 W + 1 W)
Adjust Functions
Audio Volume / Lock-Out; Auto Adjust; Brightness; Colour Temperature Control; Contrast; Control Sync; DV Mode; EcoMode; Fine Adjust (analog); Human Sensing; Intelligent Power Management; Language Select; LED Brightness; Monitor Information; NTAA (Non-Touch-Auto-Adjustment); On-Screen-Display (OSD) lock-out; One Touch Recovery; Power-Off Timer; sRGB
Shipping Content
Control Sync Cable; DisplayPort cable; Monitor; Power Cable; Setup Guide; USB Cable
Safety and Ergonomics
CE; EAC; EnergyStar 8.0; ErP; Flicker-free; ISO 9241-307 (pixel failure class I); Low Blue Light; PSB; RoHS; TCO 8.0; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA; WEEE
Warranty
3 years warranty incl. backlight; optional 1st to 3rd year 24/7 usage warranty; optional 4th to 5th year warranty extension
Green Features
Energy Efficiency
Ambient light sensor; Energy consumption: 12 kWh/1000 h; Energy efficiency class: C; Human sensor; Intelligent power management
Ecological Materials
Downloadable manuals
Ecological Standards
Energy Star 8.0; TCO 8.0
* EnergyStar 8.0
* TCO 8.0
